Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV438567 – circuit breaker ComPact NSX100F AC/DC, 18 kA at 240 VAC, TMD trip unit 50 A, 1 pole 1d Schneider Electric
Order code
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
R2 314.10
Excluding VAT · per unit · volume pricing available on request
End of commercialisation announced. Replaced by ComPacT NSX (new generation). See ComPacT NSX products · Schneider Electric substitution guide (opens in a new tab) Ask us to confirm remaining stock or to quote the replacement.
Listed in stock — availability is re-confirmed on every order
Circuit breaker ComPact NSX100F AC/DC, 18 kA at 240 VAC, TMD trip unit 50 A, 1 pole 1d — Schneider Electric order code LV438567. Rated current 50 A; 1P 1d; breaking capacity 18 kA at 240 V AC; rated voltage 240 V AC.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV438567 — Circuit breaker ComPact NSX100F AC/DC, 18 kA at 240 VAC, TMD trip unit 50 A, 1 pole 1d from the Schneider Electric Compact NSX <630 range.
Key specifications: rated current 50 A; 1P 1d; breaking capacity 18 kA at 240 V AC; rated voltage 240 V AC.
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/11/10, last orders 2022/03/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Ordering information
- Order code:
LV438567 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480073496
- Supplied: each
- Weight: 0.733 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV438567
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Number of poles | Filter products by 1P 1d |
|---|---|
| Rated current (Iu) | Filter products by 50 A |
| Rated voltage (Ue) | Filter products by 240 V AC |
| Operating Voltage | Filter products by 240 VAC |
| Max Break Capacity | Filter products by 18 kA at 240 V AC |
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Filter products by LV438567 |
| Iternational GTIN | Filter products by 3606480073496 |
| Mount Type | Filter products by Plug-in |
