Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV429760 – Circuit breaker ComPact NSX100H, 70 kA at 415 VAC, MA trip unit 100 A, 3 poles 3d | Schneider Electric
Order code
List R5 941.20 Your price R4 040.02
Per unit · volume pricing available on request
excl. VAT R4 646.02 incl.
Discontinued — remaining stock confirmed on quote
Circuit breaker ComPact NSX100H, 70 kA at 415 VAC, MA trip unit 100 A, 3 poles 3d — Schneider Electric order code LV429760. Rated current 100 A; 3P 3d; breaking capacity 70 kA at 415 V AC; rated voltage 415 V AC.
Discontinued — remaining stock confirmed on quote
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV429760 — Circuit breaker ComPact NSX100H, 70 kA at 415 VAC, MA trip unit 100 A, 3 poles 3d from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV429760
This Compact NSX100H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 100A rating magnetic trip unit (MA). MA trip unit provides an adjustable magnetic protection for instantaneous tripping. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100H is part of Schneider Electric EcoStruxure Power architecture.
LV429760 key specifications
Key specifications: rated current 100 A; 3P 3d; breaking capacity 70 kA at 415 V AC; rated voltage 415 V AC.
Availability and replacement
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV429760
- Order code:
LV429760 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480009372
- Supplied: each
- Weight: 1.802 kg
- ETIM class: EC000074
- Datasheet: manufacturer datasheet for LV429760
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV429760 — frequently asked questions
What is the rated current of LV429760?
LV429760 is rated 100 A.
How many poles does LV429760 have?
LV429760 is a 3P 3d device.
What is the breaking capacity of LV429760?
The catalogue states 70 kA at 415 V AC for LV429760. Check the datasheet for the value at your system voltage.
Is LV429760 discontinued, and what replaces it?
Yes. Schneider Electric has announced the end of commercialisation of LV429760 (last orders 2023/12/31). The named successor is ComPacT NSX (new generation); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for LV429760?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV429760 a genuine Schneider Electric product?
Yes. LV429760 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products by LV429760 – circuit breaker ComPact NSX100H, 70 kA at 415 VAC, MA trip unit 100 A, 3 poles 3d Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480009372 |
| Lifecycle status | Filter products by Discontinued |
| ETIM class | Filter products by EC000074 |
Electrical ratings
| Number of poles | Filter products by 3P 3d |
|---|---|
| Rated current (Iu) | Filter products by 100 A |
| Rated voltage (Ue) | Filter products by 415 V AC |
| Operating Voltage | Filter products by 415 VAC |
| Max Break Capacity | Filter products by 70 kA at 415 V AC |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Discontinued on | Filter products by 2024-01-03 |
|---|---|
| Breaking capacity icu | Filter products by 70 kA at 415 V |
| Replaced by | Filter products by C10H3MA100 |
| Trip unit rating | Filter products by 100 A |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | Search products for LV429760 |
| Iternational GTIN | 3606480009372 |
| Mount Type | Filter products by Plug-in |
