LV433625 – circuit breaker ComPact NSX400HB1, 75 kA at 690 VAC, MicroLogic 2.3 M trip unit 320 A, 3 poles 3d Schneider Electric
Order code
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
R25 860.88
Excluding VAT · per unit · volume pricing available on request
End of commercialisation announced. Replaced by ComPacT NSX (new generation). See ComPacT NSX products · Schneider Electric substitution guide (opens in a new tab) Ask us to confirm remaining stock or to quote the replacement.
Listed in stock — availability is re-confirmed on every order
Circuit breaker ComPact NSX400HB1, 75 kA at 690 VAC, MicroLogic 2.3 M trip unit 320 A, 3 poles 3d — Schneider Electric order code LV433625. Rated current 320 A; 3P 3d; breaking capacity 75 kA at 690 V AC; rated voltage 690 V AC.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV433625 — Circuit breaker ComPact NSX400HB1, 75 kA at 690 VAC, MicroLogic 2.3 M trip unit 320 A, 3 poles 3d from the Schneider Electric Compact NSX <630 range.
This Compact NSX400HB1 is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 85kA rms at 500VAC 50/60Hz and 75kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 2.3 M trip unit, with 320A rating. Micrologic 2.3 M trip unit provides adjustable long time and short time protections, and fixed instantaneous protection. This 3 poles version (140mm x 255mm x 110mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX400HB1 is part of Schneider Electric EcoStruxure Power architecture.
Key specifications: rated current 320 A; 3P 3d; breaking capacity 75 kA at 690 V AC; rated voltage 690 V AC; fixed mounting.
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Ordering information
- Order code:
LV433625 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480480935
- Supplied: each
- Weight: 5.775 kg
- ETIM class: EC000074
- Datasheet: manufacturer datasheet for LV433625
