LV433212 – circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, TMD trip unit 50 A, 3 poles 3d Schneider Electric

LV433212 – circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, TMD trip unit 50 A, 3 poles 3d Schneider Electric This Compact NSX100HB1 is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 85kA rms at 500VAC 50/60Hz and 75kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 50A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100HB1 is part of Schneider Electric EcoStruxure Power architecture. circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, TMD trip unit 50 A, 3 poles 3d LV433212 – Compact NSX <630

LV433212 – circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, TMD trip unit 50 A, 3 poles 3d Schneider Electric is a Schneider Electric product designed for professional electrical, automation, and infrastructure applications.

This product forms part of the ComPacT range and is suitable for installers, contractors, panel builders, maintenance teams, and buyers looking for reliable Schneider Electric components with proven performance and compatibility.

Technical Specifications

• Brand: Schneider Electric
• Series: ComPacT
• Amperage: 50 A
• Voltage: 690 VAC
• Poles: 3P
• Breaking Capacity: 75 kA
• Mount Type: Fixed

Key Features

• Part of the ComPacT range
• Rated at 50 A
• Suitable for 690 VAC applications
• 3P configuration
• 75 kA breaking capacity
• Fixed installation format

Applications

• Industrial automation
• Commercial electrical installations
• Control and protection systems
• Infrastructure and maintenance projects
