Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV438598 – Circuit breaker ComPact NSX100F AC/DC, 18 kA at 415 VAC, TMD trip unit 63 A, 2 poles 2d | Schneider Electric
Order code
List R3 380.34 Your price R2 298.63
Per unit · volume pricing available on request
excl. VAT R2 643.42 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Circuit breaker ComPact NSX100F AC/DC, 18 kA at 415 VAC, TMD trip unit 63 A, 2 poles 2d — Schneider Electric order code LV438598. Rated current 63 A; 2P 2d; breaking capacity 18 kA at 415 V AC; rated voltage 415 V AC.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Rating63 A22 options
Breaking capacity18 kA at 415 V AC13 options
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV438598 — Circuit breaker ComPact NSX100F AC/DC, 18 kA at 415 VAC, TMD trip unit 63 A, 2 poles 2d from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
LV438598 key specifications
Key specifications: rated current 63 A; 2P 2d; breaking capacity 18 kA at 415 V AC; rated voltage 415 V AC.
Availability and replacement
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV438598
- Order code:
LV438598 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480073779
- Supplied: each
- Weight: 1.242 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV438598
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV438598 — frequently asked questions
What is the rated current of LV438598?
LV438598 is rated 63 A.
How many poles does LV438598 have?
LV438598 is a 2P 2d device.
What is the breaking capacity of LV438598?
The catalogue states 18 kA at 415 V AC for LV438598. Check the datasheet for the value at your system voltage.
Is LV438598 discontinued, and what replaces it?
Yes. Schneider Electric has announced the end of commercialisation of LV438598 (last orders 2023/12/31). The named successor is ComPacT NSX (new generation); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for LV438598?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV438598 a genuine Schneider Electric product?
Yes. LV438598 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV438598 – circuit breaker ComPact NSX100F AC/DC, 18 kA at 415 VAC, TMD trip unit 63 A, 2 poles 2d Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480073779 |
| Lifecycle status | Filter products by End of commercialisation announced |
| ETIM class | Filter products by EC000228 |
Electrical ratings
| Number of poles | Filter products by 2P 2d |
|---|---|
| Rated current (Iu) | Filter products by 63 A |
| Rated voltage (Ue) | Filter products by 415 V AC |
| Operating Voltage | Filter products by 415 VAC |
| Max Break Capacity | Filter products by 18 kA at 415 V AC |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Trip unit | Filter products by TMD |
|---|---|
| Trip unit rating | Filter products by 63 A |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | LV438598 |
| Iternational GTIN | 3606480073779 |
| Mount Type | Filter products by Plug-in |
