LV433309 – Circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, MicroLogic 5.2 E trip unit 100 A, 3 poles 3d | Schneider Electric
Order code
List R16 863.44 Your price R11 467.14
Per unit · volume pricing available on request
excl. VAT R13 187.21 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, MicroLogic 5.2 E trip unit 100 A, 3 poles 3d — Schneider Electric order code LV433309. Rated current 100 A; 3P 3d; breaking capacity 75 kA at 690 V AC; rated voltage 690 V AC.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Rating100 A22 options
Breaking capacity75 kA at 690 V AC13 options
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV433309 — Circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, MicroLogic 5.2 E trip unit 100 A, 3 poles 3d from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV433309
This Compact NSX100HB1 is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 85kA rms at 500VAC 50/60Hz and 75kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 5.2 E trip unit, with 100A rating. Micrologic 5.2 E trip unit provides adjustable long time, short time and instantaneous protection. Micrologic 5.2 E has an embedded display unit for fine settings adjustment and display of the energy (energy meter). This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100HB1 is part of Schneider Electric EcoStruxure Power architecture.
LV433309 key specifications
Key specifications: rated current 100 A; 3P 3d; breaking capacity 75 kA at 690 V AC; rated voltage 690 V AC.
Availability and replacement
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV433309
- Order code:
LV433309 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480479540
- Supplied: each
- Weight: 1.992 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV433309
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV433309 — frequently asked questions
What is the rated current of LV433309?
LV433309 is rated 100 A.
How many poles does LV433309 have?
LV433309 is a 3P 3d device.
What is the breaking capacity of LV433309?
The catalogue states 75 kA at 690 V AC for LV433309. Check the datasheet for the value at your system voltage.
Is LV433309 discontinued, and what replaces it?
Yes. Schneider Electric has announced the end of commercialisation of LV433309 (last orders 2023/12/31). The named successor is ComPacT NSX (new generation); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for LV433309?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV433309 a genuine Schneider Electric product?
Yes. LV433309 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV433309 – circuit breaker ComPact NSX100HB1, 75 kA at 690 VAC, MicroLogic 5.2 E trip unit 100 A, 3 poles 3d Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480479540 |
| Lifecycle status | Filter products by End of commercialisation announced |
| ETIM class | Filter products by EC000228 |
Electrical ratings
| Number of poles | Filter products by 3P 3d |
|---|---|
| Rated current (Iu) | Filter products by 100 A |
| Rated voltage (Ue) | Filter products by 690 V AC |
| Operating Voltage | Filter products by 690 VAC |
| Max Break Capacity | Filter products by 75 kA at 690 V AC |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Breaking capacity icu | Filter products by 75 kA at 690 V / 85 kA at 500 V |
|---|---|
| Trip unit | Filter products by MicroLogic 5.2 |
| Trip unit rating | Filter products by 100 A |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | LV433309 |
| Iternational GTIN | 3606480479540 |
| Mount Type | Filter products by Plug-in |
