Save 32%
Modular single phase power meter iEM2155 - 230V - 63A with comm Modbus - MID

Schneider ElectricEnergy Meters

A9MEM2155 – Modular single phase power meter iEM2155 – 230V – 63A with comm Modbus – MID | Schneider Electric

Order code

Select a variant in this series

Rating

Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.

List price

List R4 900.10 Your price R3 332.07

Excluding VAT · per unit · volume pricing available on request

Listed in stock — availability is re-confirmed on every order

Modular single phase power meter iEM2155 – 230V – 63A with comm Modbus – MID — Schneider Electric order code A9MEM2155.

Download datasheet (opens in a new tab)

Ordering & delivery
  • Contact us for bulk pricing, lead times and ordering codes.
  • Minimum order: 1 unit.
  • Manufacturer's standard warranty applies.
  • Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
  • Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
  • Authorised Schneider Electric distributor
  • Genuine product with manufacturer warranty
  • Formal quotations with written lead times
SKU: A9MEM2155 Category: Brand:

Overview

A9MEM2155 — Modular single phase power meter iEM2155 – 230V – 63A with comm Modbus – MID by Schneider Electric. Listed under Energy Meters on the Schneider Electric catalogue at RMS-SE.Africa.

About A9MEM2155

The Acti9 iEM2100 series energy meters offer is a single-phase DIN rail-mounted energy meters fitted for basic metering. This product family can be used to monitor power consumption for each sector, unit or workshop and manage electrical installation for building management. It feature a 8-character LCD display and red LED indicator to display measured electrical parameters. Providing Class 1 active energy accuracy per IEC 62053-21 standard, the meter will measure Active and Reactive Power, Active and Reactive Energy, Voltage and Current. Suitable for a 230VAC network, with a supply voltage range of 96 to 276 VAC at 50Hz or 60Hz. Direct connect current measurement up to 63A with 32 samples per cycle only in a Single Phase and Neutral configuration. Communication protocol is M-Bus with 3 wire terminal support, no additional communication ports. You will have the possibility to switch between 2 tariffs thanks to a dedicated tariff switching input. Product dimensions are as follows: width 36 mm, depth 64 mm, height 90 mm and product weight 175 g. This version is compliant with the standard EN 50470-3 class B, Measuring Instruments Directive (MID). Compatible with power management software to take advantage of the IoT digital power installation.

Ordering information for A9MEM2155

Prices in ZAR excluding VAT; stock and lead time are confirmed on every written quotation from RMS Measurement & Control, Johannesburg.

Technical specifications

Data supplied by the manufacturer. Confirm against the official datasheet before ordering.

Identification & ordering

BrandFilter products by Schneider Electric
GTIN / EANFilter products by 3606485434667
RangeFilter products by iEM2000 series
Lifecycle statusFilter products by Current
ETIM classFilter products by EC001506

Documents

DatasheetDownload datasheet

Other specifications

SKU/Code/PartnumberFilter products by A9MEM2155

Documents

Published by the manufacturer for this part. Each one opens in a new tab.

More in the iEM2000 series range

6 items

Same series, same mounting and the same documentation set.

Similar items

6 items

More in Energy Meters

8 items

Alternatives on our other RMS storefronts

RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.

Quick answers

What is A9MEM2155?

A9MEM2155 is the order code for Modular single phase power meter iEM2155 – 230V – 63A with comm Modbus – MID. It belongs to our Energy Meters range. RMS-SE.Africa supplies it as genuine Schneider Electric product, sourced through the manufacturer's distribution channel.

Is it available?

It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.

How do I get a formal quotation?

Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.

Do I pay when I order?

No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
