TelemecaniquePhotoelectric Sensors
XZCP1141L5 – Pre wired connectors XZ, straight female, M12, 4 pins, cable PUR 5 m Telemecanique Sensors
Order code
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
R533.59
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Pre wired connectors XZ, straight female, M12, 4 pins, cable PUR 5 m — Telemecanique Sensors order code XZCP1141L5. Rated current 4 A; rated voltage 250 V; IP65.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
XZCP1141L5 — Pre wired connectors XZ, straight female, M12, 4 pins, cable PUR 5 m, a photoelectric sensor from the Telemecanique Sensors OsiSense XU range.
This product is part of the XZ range, an offer of cordsets and connectors. This cable is made up of 4 wires and has a 4 pins M12 straight female connector with a metal collar. It is designed in polyurethane for severe industrial environments. Its rated operational voltage is 250V/AC or 300V/DC and its nominal current is 4A. Its contact resistance is 5000µOhm and its minimum insulating resistance is 1GΩ. It is dustproof, resistant to water jets (IP65), can be temporarily immersed in water (IP67), and withstands high pressure and steam cleaning (IP69K). This cable has a length of 5m and a diameter of 5.2mm. It is made up of 4 wires, each section of which is 0.34 mm². Its color is black and its weight is 0.19kg. It is intended for industrial environments thanks to its excellent resistance to extreme temperatures (-35°C to +90°C in operation if the cable remains static). This cable complies with cULus certification. It is compatible with a 5 pins M12 male connector. XZ range includes a wide range of cordsets, connectors, and connection boxes designed for a simple connection process and a quick reference identification.
Key specifications: rated current 4 A; rated voltage 250 V; IP65.
Ordering information
- Order code:
XZCP1141L5 - Manufacturer: Telemecanique Sensors (formerly Telemecanique)
- Range: OsiSense XU
- GTIN / EAN: 3389110763188
- Supplied: each
- Weight: 0.154 kg
- ETIM class: EC001855
- Datasheet: manufacturer datasheet for XZCP1141L5
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Rated current (Iu) | Filter products by 4 A |
|---|---|
| Rated voltage (Ue) | Filter products by 250 V |
| Operating Voltage | Filter products by 250V |
Environment & protection
| Degree of protection (IP) | Filter products by IP65 |
|---|
Other specifications
| SKU/Code/Partnumber | Filter products by XZCP1141L5 |
|---|---|
| Iternational GTIN | Filter products by 3389110763188 |
