Schneider ElectricMiniature Circuit Breakers (MCB's)
M9U21103 – Multi9 – C60H-DC – MCB – 1P – 3 A – C Curve – 250 V DC – 10 kA | Schneider Electric
Order code
List R1 228.97 Your price R835.70
Per unit · volume pricing available on request
excl. VAT R961.06 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Multi9 – C60H-DC – MCB – 1P – 3 A – C Curve – 250 V DC – 10 kA — Schneider Electric order code M9U21103. Rated current 3 A; 1P; breaking capacity 10 kA; C curve.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
CurveC2 options
- C
- D
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
M9U21103 — Multi9 – C60H-DC – MCB – 1P – 3 A – C Curve – 250 V DC – 10 kA, a miniature circuit breaker from the Schneider Electric C60 UL/CSA/IEC range. Listed under Miniature Circuit Breakers (MCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About M9U21103
This Multi9 C60H-DC is a low voltage miniature circuit breaker (MCB) dedicated to direct current. It is a 1P circuit breaker with 1 protected pole, 3A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10kA at 220VDC conforming to EN/IEC 60947-2 standard and 10kA at 220VDC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 3000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 250VDC. The Ui rated insulation voltage is 500VDC. The Uimp rated impulse withstand voltage is 6kV. The product can be clipped on a DIN rail. Its width is 2 pitches of 9mm. Pollution degree is 3. The product colour is light grey (RAL7035). The dimensions are (W) 18mm x (H) 81mm x (D) 73mm. The weight is 0.128kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -25°C to 70°C. The storage temperature is -40°C to 85°C.
M9U21103 key specifications
Key specifications: rated current 3 A; 1P; breaking capacity 10 kA; C curve; rated voltage 250 V; IP20; DIN rail mounting.
Ordering information for M9U21103
- Order code:
M9U21103 - Manufacturer: Schneider Electric
- Range: C60 UL/CSA/IEC
- GTIN / EAN: 3606480741609
- Supplied: each
- Weight: 0.116 kg
- ETIM class: EC000042
- Datasheet: manufacturer datasheet for M9U21103
About the C60 UL/CSA/IEC range
C60 UL/CSA/IEC is a Schneider Electric range with 13 references listed on RMS-SE.Africa, from 2 A to 25 A.
M9U21103 — frequently asked questions
What is the rated current of M9U21103?
M9U21103 is rated 3 A.
How many poles does M9U21103 have?
M9U21103 is a 1P device.
What is the breaking capacity of M9U21103?
The catalogue states 10 kA for M9U21103. Check the datasheet for the value at your system voltage.
Where is the datasheet for M9U21103?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is M9U21103 a genuine Schneider Electric product?
Yes. M9U21103 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | M9U21103 – Multi9 – C60H-DC – MCB – 1P – 3 A – C Curve – 250 V DC – 10 kA Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by C60 UL/CSA/IEC |
| GTIN / EAN | 3606480741609 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000042 |
Electrical ratings
| Number of poles | Filter products by 1P |
|---|---|
| Rated current (Iu) | Filter products by 3 A |
| Rated voltage (Ue) | Filter products by 250 V |
| Tripping curve | Filter products by C |
| Max Break Capacity | Filter products by 10 kA |
Mechanical & mounting
| Mounting | Filter products by DIN rail |
|---|
Environment & protection
| Degree of protection (IP) | Filter products by IP20 |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Breaking capacity icu | Filter products by 10 kA at 220 V |
|---|---|
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | M9U21103 |
| Iternational GTIN | 3606480741609 |
