Merlin GerinMoulded Case Circuit Breakers (MCCBs)
EZC250F3150 – Circuit Breaker Easypact, EZC250F, TMD, 150 A, 3 poles 3d | Schneider Electric
Order code
List R3 049.00 Your price R2 073.32
Per unit · volume pricing available on request
excl. VAT R2 384.32 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Circuit Breaker Easypact, EZC250F, TMD, 150 A, 3 poles 3d — Schneider Electric order code EZC250F3150. Rated current 150 A; 3P 3d; breaking capacity 18 kA; rated voltage 415 V.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Rating150 A24 options
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
EZC250F3150 — Circuit Breaker Easypact, EZC250F, TMD, 150 A, 3 poles 3d from the Schneider Electric EasyPact EZC range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About EZC250F3150
EasyPact EZC250F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 18kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 150A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250F is compliant with international standards (IEC 60947, UL 508) and marine certifications.
EZC250F3150 key specifications
Key specifications: rated current 150 A; 3P 3d; breaking capacity 18 kA; rated voltage 415 V.
Ordering information for EZC250F3150
- Order code:
EZC250F3150 - Manufacturer: Schneider Electric (formerly Merlin Gerin)
- Range: EasyPact EZC
- GTIN / EAN: 3303431999972
- Supplied: each
- Weight: 1.64 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for EZC250F3150
About the EasyPact EZC range
EasyPact EZC is a Schneider Electric range with 188 references listed on RMS-SE.Africa, from 15 A to 600 A.
EZC250F3150 — frequently asked questions
What is the rated current of EZC250F3150?
EZC250F3150 is rated 150 A.
How many poles does EZC250F3150 have?
EZC250F3150 is a 3P 3d device.
What is the breaking capacity of EZC250F3150?
The catalogue states 18 kA for EZC250F3150. Check the datasheet for the value at your system voltage.
Where is the datasheet for EZC250F3150?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is EZC250F3150 a genuine Schneider Electric product?
Yes. EZC250F3150 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products by EZC250F3150 – Circuit Breaker Easypact, EZC250F, TMD, 150 A, 3 poles 3d Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by EasyPact EZC |
| GTIN / EAN | 3303431999972 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000228 |
Electrical ratings
| Number of poles | Filter products by 3P 3d |
|---|---|
| Rated current (Iu) | Filter products by 150 A |
| Rated voltage (Ue) | Filter products by 415 V |
| Operating Voltage | Filter products by 415VAC |
| Max Break Capacity | Filter products by 18 kA |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Trip unit | Filter products by thermal-magnetic |
|---|---|
| Breaking capacity icu | Filter products by 18 kA at 415 V |
| Trip unit rating | Filter products by 150 A |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | Search products for EZC250F3150 |
| Iternational GTIN | 3303431999972 |
| Mount Type | Filter products by Plug-in |
