CAD32BL – TeSys D control relay – 3 NO + 2 NC – <= 690 V - 24 V DC low consumption coil | Schneider Electric
Order code
List R934.00 Your price R635.12
Per unit · volume pricing available on request
excl. VAT R730.39 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
TeSys D control relay – 3 NO + 2 NC – <= 690 V - 24 V DC low consumption coil — Schneider Electric order code CAD32BL. Rated current 10 A; rated voltage 690 V; DIN rail mounting.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
CAD32BL — TeSys D control relay – 3 NO + 2 NC – <= 690 V – 24 V DC low consumption coil, a contactor from the Schneider Electric TeSys k, d, SK (auxiliary contactors) range. Listed under Contactors on the Schneider Electric catalogue at RMS-SE.Africa.
About CAD32BL
TeSys D control relay, 5 contacts (3NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a low consumption 24V DC control circuit with no inrush consumption and equipped with a surge suppression device, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -40/+60°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium product (RoHS/REACh).
CAD32BL key specifications
Key specifications: rated current 10 A; rated voltage 690 V; DIN rail mounting.
Ordering information for CAD32BL
- Order code:
CAD32BL - Manufacturer: Schneider Electric (formerly Telemecanique)
- Range: TeSys k, d, SK (auxiliary contactors)
- GTIN / EAN: 3389110407082
- Supplied: each
- Weight: 0.531 kg
- ETIM class: EC000196
- Datasheet: manufacturer datasheet for CAD32BL
About the TeSys k, d, SK (auxiliary contactors) range
TeSys k, d, SK (auxiliary contactors) is a Schneider Electric range with 74 references listed on RMS-SE.Africa. Coil voltages in the range: 110 V AC, 24 V AC, 230 V AC, 48 V AC, 380…400 V AC. It spans Mini Contactors, Contactors, Motor Control & Drives.
CAD32BL — frequently asked questions
What is the rated current of CAD32BL?
CAD32BL is rated 10 A.
Where is the datasheet for CAD32BL?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is CAD32BL a genuine Schneider Electric product?
Yes. CAD32BL is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products by CAD32BL – TeSys D control relay – 3 NO + 2 NC – <= 690 V – 24 V DC low consumption coil Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by TeSys k, d, SK (auxiliary contactors) |
| GTIN / EAN | 3389110407082 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000196 |
Electrical ratings
| Rated current (Iu) | Filter products by 10 A |
|---|---|
| Rated voltage (Ue) | Filter products by 690 V |
Mechanical & mounting
| Mounting | Filter products by DIN rail |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Search products for CAD32BL |
| Iternational GTIN | 3389110407082 |
