Schneider ElectricPhotoelectric Sensors
XU5M18MA230K – Photoelectric sensors XU, XU5, diffuse, Sn 0.4 m, 24…240VAC/DC, 1/2″ | Telemecanique Sensors
Order code
List R3 566.40 Your price R2 425.15
Per unit · volume pricing available on request
excl. VAT R2 788.92 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Photoelectric sensors XU, XU5, diffuse, Sn 0.4 m, 24…240VAC/DC, 1/2″ — Telemecanique Sensors order code XU5M18MA230K. Rated voltage 240 V; IP67.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
XU5M18MA230K — Photoelectric sensors XU, XU5, diffuse, Sn 0.4 m, 24…240VAC/DC, 1/2" from the Telemecanique Sensors OsiSense XU range. Listed under Photoelectric Sensors on the Telemecanique Sensors catalogue at RMS-SE.Africa.
About XU5M18MA230K
This product is part of the XU range, an offer of photoelectric sensors. This photoelectric sensor in a cylindrical M18 design with diffuse detection system. It supports 0.4m diffuse nominal sensing distance and 1 NO discrete output. The photoelectric sensor with a rated supply voltage of 24V to 240V AC/DC and maximum residual current of 1.5mA open state. It is furnished with 3-pin 1/2-20 UNF male connector for electrical connection. It is an IP67 rated product. The enclosure is made of nickel plated brass with PMMA lens. Its dimensions are 18mm (diameter) x 95mm (length). It weighs 0.075kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. This product is certified by CE, CSA and UL. The XU is for non contact sensing up to a hundred meters of objects of any shape and any type. The XU range offers a full line of photoelectric proximity sensors dedicated to material handling, packaging, labelling, lift, food and beverage industries.
XU5M18MA230K key specifications
Key specifications: rated voltage 240 V; IP67.
Ordering information for XU5M18MA230K
- Order code:
XU5M18MA230K - Manufacturer: Telemecanique Sensors (formerly Telemecanique)
- Range: OsiSense XU
- GTIN / EAN: 3389110736595
- Supplied: each
- Weight: 0.084 kg
- ETIM class: EC001821
- Datasheet: manufacturer datasheet for XU5M18MA230K
About the OsiSense XU range
OsiSense XU is a Telemecanique Sensors range with 228 references listed on RMS-SE.Africa.
XU5M18MA230K — frequently asked questions
Where is the datasheet for XU5M18MA230K?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Telemecanique Sensors publishes them.
Is XU5M18MA230K a genuine Telemecanique Sensors product?
Yes. XU5M18MA230K is supplied through the manufacturer’s authorised channel with the standard Telemecanique Sensors warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | XU5M18MA230K – Photoelectric sensors XU, XU5, diffuse, Sn 0.4 m, 24…240VAC/DC, 1/2" Telemecanique Sensors |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by OsiSense XU |
| GTIN / EAN | 3389110736595 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC001821 |
Electrical ratings
| Rated voltage (Ue) | Filter products by 240 V |
|---|---|
| Operating Voltage | Filter products by 240VAC |
Environment & protection
| Degree of protection (IP) | Filter products by IP67 |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| SKU/Code/Partnumber | XU5M18MA230K |
|---|---|
| Iternational GTIN | 3389110736595 |
