Schneider ElectricLimit Switches
XC1AC117 – Limit switch, Limit switches XC Standard, XC1AC, reinforced roller lever, 1C/O | Telemecanique Sensors
Order code
List R5 997.84 Your price R4 078.53
Per unit · volume pricing available on request
excl. VAT R4 690.31 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Limit switch, Limit switches XC Standard, XC1AC, reinforced roller lever, 1C/O — Telemecanique Sensors order code XC1AC117. Rated current 10 A; IP65; fixed mounting.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Rating10 A2 options
- 3 A
- 10 A
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
XC1AC117 — Limit switch, Limit switches XC Standard, XC1AC, reinforced roller lever, 1C/O from the Telemecanique Sensors OsiSense XC Special range. Listed under Limit Switches on the Telemecanique Sensors catalogue at RMS-SE.Africa.
About XC1AC117
This product is part of the XC Special range, an offer of limit switches. This limit switch is a device that converts a mechanical motion into an electrical control signal. It has 1 change over, slow-break contacts without positive opening operation and provides switch actuation by 30° cam. It has a spring return metal reinforced roller lever and supports lateral approach in 2 directions. The movement of limit switch operating head is linear. It is furnished with screw clamp terminals for electrical connection and 3 entry tapped for PG13.5 cable gland. It is an IP65 rated product. It is a switch with a conventional enclosed thermal current of 10A. It offers long mechanical and electrical life, the mechanical durability is about 10 million operating cycles and electrical durability is 1 million operating cycles. This limit switch has a fixed type body which is made of metal. Its dimensions are 77mm (Width) x 44mm (Depth) x 139mm (Height) and weighs 0.595kg. It is suitable for hoisting and material handling applications. This product is certified by CSA. It meets IEC 60337-1, IEC 60947-5-1.
XC1AC117 key specifications
Key specifications: rated current 10 A; IP65; fixed mounting.
Availability and replacement
Availability notice: Telemecanique Sensors has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Telemecanique Sensors names Telemecanique Sensors XC Standard (XCKJ) as the successor to the OsiSense XC Special range. Reference-level successor shown on telemecaniquesensors.com product pages. Ask the sales desk to confirm the exact replacement reference before ordering.
Ordering information for XC1AC117
- Order code:
XC1AC117 - Manufacturer: Telemecanique Sensors (formerly Telemecanique)
- Range: OsiSense XC Special
- GTIN / EAN: 3389110315141
- Supplied: each
- Weight: 0.9 kg
- ETIM class: EC000030
- Datasheet: manufacturer datasheet for XC1AC117
About the OsiSense XC Special range
OsiSense XC Special is a Telemecanique Sensors range with 83 references listed on RMS-SE.Africa, from 3 A to 10 A. Telemecanique Sensors has announced Telemecanique Sensors XC Standard (XCKJ) as its successor.
XC1AC117 — frequently asked questions
What is the rated current of XC1AC117?
XC1AC117 is rated 10 A.
Is XC1AC117 discontinued, and what replaces it?
Yes. Telemecanique Sensors has announced the end of commercialisation of XC1AC117 (last orders 2023/12/31). The named successor is Telemecanique Sensors XC Standard (XCKJ); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for XC1AC117?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Telemecanique Sensors publishes them.
Is XC1AC117 a genuine Telemecanique Sensors product?
Yes. XC1AC117 is supplied through the manufacturer’s authorised channel with the standard Telemecanique Sensors warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | XC1AC117 – Limit switch, Limit switches XC Standard, XC1AC, reinforced roller lever, 1C/O Telemecanique Sensors |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by OsiSense XC Special |
| GTIN / EAN | 3389110315141 |
| Lifecycle status | Filter products by End of commercialisation announced |
| ETIM class | Filter products by EC000030 |
Electrical ratings
| Rated current (Iu) | Filter products by 10 A |
|---|
Mechanical & mounting
| Mounting | Filter products by fixed |
|---|
Environment & protection
| Degree of protection (IP) | Filter products by IP65 |
|---|---|
| Ambient air temperature | Filter products by 1C |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| SKU/Code/Partnumber | XC1AC117 |
|---|---|
| Iternational GTIN | 3389110315141 |
