Schneider ElectricPushbuttons & Selector Switches
XB7NW38M1 – Harmony XB7, Monolithic illuminated push button, plastic, yellow, Ø22, integral LED, spring return, 230…240 V AC, 1 NO | Schneider Electric
Order code
List R458.73 Your price R311.94
Per unit · volume pricing available on request
excl. VAT R358.73 incl.
Discontinued — remaining stock confirmed on quote
Harmony XB7, Monolithic illuminated push button, plastic, yellow, Ø22, integral LED, spring return, 230…240 V AC, 1 NO — Schneider Electric order code XB7NW38M1. Rated voltage 240 V; IP65.
Discontinued — remaining stock confirmed on quote
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
XB7NW38M1 — Harmony XB7, Monolithic illuminated push button, plastic, yellow, Ø22, integral LED, spring return, 230…240 V AC, 1 NO, a pushbuttons and selector switch by Schneider Electric. Listed under Pushbuttons & Selector Switches on the Schneider Electric catalogue at RMS-SE.Africa.
About XB7NW38M1
This Harmony XB7, illuminated projecting monolithic yellow push button operates with a spring return mechanism, is supplied with 230V AC, uses an integral LED and screw clamp terminals. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, minimizing errors in machine control and enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. It has a double insulated plastic bezel. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
XB7NW38M1 key specifications
Key specifications: rated voltage 240 V; IP65.
Ordering information for XB7NW38M1
- Order code:
XB7NW38M1 - Manufacturer: Schneider Electric
- Range: Harmony XB7
- GTIN / EAN: 3606480471001
- Supplied: each
- Weight: 0.025 kg
- ETIM class: EC001028
- Datasheet: manufacturer datasheet for XB7NW38M1
About the Harmony XB7 range
Harmony XB7 is a Schneider Electric range with 59 references listed on RMS-SE.Africa. It spans Pushbuttons & Selector Switches, Pilot Lights.
XB7NW38M1 — frequently asked questions
Where is the datasheet for XB7NW38M1?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is XB7NW38M1 a genuine Schneider Electric product?
Yes. XB7NW38M1 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | XB7NW38M1 – Harmony XB7, Monolithic illuminated push button, plastic, yellow, Ø22, integral LED, spring return, 230…240 V AC, 1 NO Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Harmony XB7 |
| GTIN / EAN | 3606480471001 |
| Lifecycle status | Filter products by Discontinued |
| ETIM class | Filter products by EC001028 |
Electrical ratings
| Rated voltage (Ue) | Filter products by 240 V |
|---|
Environment & protection
| Degree of protection (IP) | Filter products by IP65 |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Discontinued on | Filter products by 2023-06-30 |
|---|---|
| Hole diameter | Filter products by 22 mm |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays, Filter products by Pushbuttons and Selector Switches |
| SKU/Code/Partnumber | XB7NW38M1 |
| Iternational GTIN | 3606480471001 |
| Mount Type | Filter products by Plug-in |
