Schneider ElectricPushbuttons & Selector Switches
XB4BP61GEX – Complete push button, Harmony XB4, Explosive atmosphere, pushbutton blue with boot | Schneider Electric
Order code
List R1 223.00 Your price R831.64
Per unit · volume pricing available on request
excl. VAT R956.39 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Complete push button, Harmony XB4, Explosive atmosphere, pushbutton blue with boot — Schneider Electric order code XB4BP61GEX. IP65; flush mounting.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Contacts1 NO2 options
- 1 NC
- 1 NO
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
XB4BP61GEX — Complete push button, Harmony XB4, Explosive atmosphere, pushbutton blue with boot, a pushbuttons and selector switch from the Schneider Electric Harmony XB4 – ATEX D range. Listed under Pushbuttons & Selector Switches on the Schneider Electric catalogue at RMS-SE.Africa.
About XB4BP61GEX
This product is part of the Harmony XB4 – ATEX D range, an offer of Ø 22mm metal pushbuttons, switches and pilot lights for explosive atmosphere. This blue pushbutton has a circular head shape with a booted, clear silicon flush push. This offer is specially designed for explosive atmosphere. It is designed for used in dust zone 21-22 and gas zone 1-2. This pushbutton with booted clear silicon provides an ergonomic and visual interface for controlling machines. It comes with 1 NO contact with slow-break operation and operates with a spring return mechanism. It has silver alloy contact material. It has a chromium plated metal bezal and has a 22mm diameter head. This offer is specially designed for applications in Oil and Gas industry as well as Food and beverage, car gas stations etc. It is an IP65 rated product and comes with INERIS 04ATEX9004U certification. It is easily installed into a standard 22mm diameter panel cut-outs and connected to control circuits with screw-clamp connections. The Harmony XB4 range offers innovative features for simple and efficient use. The Harmony XB4 – ATEX is the most comprehensive explosive Atmospheres range covering most applications.
XB4BP61GEX key specifications
Key specifications: IP65; flush mounting.
Ordering information for XB4BP61GEX
- Order code:
XB4BP61GEX - Manufacturer: Schneider Electric
- Range: Harmony XB4 – ATEX D
- GTIN / EAN: 3606489485948
- Supplied: each
- Weight: 0.104 kg
- ETIM class: EC001028
- Datasheet: manufacturer datasheet for XB4BP61GEX
About the Harmony XB4 – ATEX D range
Harmony XB4 – ATEX D is a Schneider Electric range with 91 references listed on RMS-SE.Africa. It spans Pushbuttons & Selector Switches, Pilot Lights.
XB4BP61GEX — frequently asked questions
Where is the datasheet for XB4BP61GEX?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is XB4BP61GEX a genuine Schneider Electric product?
Yes. XB4BP61GEX is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products by XB4BP61GEX – Complete push button, Harmony XB4, Explosive atmosphere, pushbutton blue with boot Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Harmony XB4 – ATEX D |
| GTIN / EAN | 3606489485948 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC001028 |
Contacts, control & I/O
| Contact configuration | Filter products by 1 NO |
|---|---|
| Actuator type | Filter products by booted push |
Mechanical & mounting
| Mounting | Filter products by flush |
|---|
Environment & protection
| Degree of protection (IP) | Filter products by IP65 |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Hole diameter | Filter products by 22 mm |
|---|---|
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays, Filter products by Pushbuttons and Selector Switches |
| SKU/Code/Partnumber | Search products for XB4BP61GEX |
| Iternational GTIN | 3606489485948 |
| Mount Type | Filter products by Flush Mount |
