TPRST038 – Direct online starter, TeSys island, 40A AC-1, 38A AC-3, 18.5kW / 20hp Schneider Electric
Order code
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
R6 354.51
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Direct online starter, TeSys island, 40A AC-1, 38A AC-3, 18.5kW / 20hp — Schneider Electric order code TPRST038. Rated current 40 A; rated voltage 690 V; DIN rail mounting.
Accessories & add-ons 1
- TeSys D control relay – 5 NO – <= 690 V – 115 V AC standard coil Schneider ElectricCAD50FE7 Original price was: R716.00.R486.88Current price is: R486.88.Add
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
TPRST038 — Direct online starter, TeSys island, 40A AC-1, 38A AC-3, 18.5kW / 20hp, a contactor by Schneider Electric.
TeSys island direct starter, 3 poles, 38A/690V. Connected to a TPRBC bus coupler it controls, protects and monitors loads up to 38A and motors up to 18,5kW@400V / 20hp@480V. It provides motor protection functions including thermal overload (setting 0.76-38A, tripping class 5-30), phase loss, phase unbalance and reversal, long start (stall), locked rotor (jam), rapid cycle lockout, ground current detection. Monitoring of the load includes max/average voltages and currents, number of switching cycles, number of faults, active and reactive power/energy when associated to a TPRVM001 voltage module. Mounting on DIN rail together with the other modules of the TeSys island configuration. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Key specifications: rated current 40 A; rated voltage 690 V; DIN rail mounting.
Ordering information
- Order code:
TPRST038 - Manufacturer: Schneider Electric
- Range: TeSys island
- GTIN / EAN: 3606489832766
- Supplied: each
- Weight: 0.77 kg
- ETIM class: EC001605
- Datasheet: manufacturer datasheet for TPRST038
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Rated current (Iu) | Filter products by 40 A |
|---|---|
| Rated voltage (Ue) | Filter products by 690 V |
| Operating Voltage | Filter products by 690V |
Mechanical & mounting
| Mounting | Filter products by DIN rail |
|---|
Other specifications
| Related Categories | Filter products by Metering, Filter products by Power Monitoring Systems |
|---|---|
| SKU/Code/Partnumber | Filter products by TPRST038 |
| Iternational GTIN | Filter products by 3606489832766 |
