Merlin GerinIndustrial Plugs & Sockets
PKF32W424 – PratiKa socket – screw – angled – 32A – 3P + E – 200…250 V AC – wall Schneider Electric
Order code
R404.21
Excluding VAT · per unit · volume pricing available on request
End of commercialisation announced. Ask us to confirm remaining stock or to quote the current replacement.
Listed in stock — availability is re-confirmed on every order
PratiKa socket – screw – angled – 32A – 3P + E – 200…250 V AC – wall — Schneider Electric order code PKF32W424. Rated current 32 A; 3P; rated voltage 250 V; IP44.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
PKF32W424 — PratiKa socket – screw – angled – 32A – 3P + E – 200…250 V AC – wall by Schneider Electric.
This Pratika industrial socket with captive screws connection is angled wall mounted. It has 3P+E poles, rated current is 32A and the operating voltage is 200VAC to 250VAC. The dimensions of the base plate are (W) 90mm x (H) 160mm. The degree of protection is IP44 and IK08. The fire resistance is 750°C. The cable entries are for flexible or rigid cables. The cross section of the cables in 32A is 2.5mm² to 10mm². The color of the socket is light grey (RAL 7035) with blue easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 9h.
Key specifications: rated current 32 A; 3P; rated voltage 250 V; IP44.
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2023/05/19, last orders 2023/06/30). Stock may still be available; ask us to confirm, or to quote the current replacement.
Ordering information
- Order code:
PKF32W424 - Manufacturer: Schneider Electric (formerly Merlin Gerin)
- Range: PratiKa
- GTIN / EAN: 3303432416171
- Supplied: each
- Weight: 0.26 kg
- ETIM class: EC001321
- Datasheet: manufacturer datasheet for PKF32W424
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated current (Iu) | Filter products by 32 A |
| Rated voltage (Ue) | Filter products by 250 V |
| Rated operational voltage | Filter products by 250 V |
| Operating Voltage | Filter products by 250 V |
Environment & protection
| Degree of protection (IP) | Filter products by IP44 |
|---|
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Filter products by PKF32W424 |
| Iternational GTIN | Filter products by 3303432416171 |
| Mount Type | Filter products by Plug-in |
