About METSEPM5310

This device is a flush-mount energy meter with a 96mm by 96mm backlit LCD display. The meter provides Class 0.5S accuracy per IEC 62053-22 standard and 64 samples per cycle. The meter will measure Energy, Active and Reactive Power, Voltage, Current, Frequency, Power Factor and up to the 31st Harmonic. Include 256 kiloBytes of memory for two fixed parameters, active and reactive energy. The meter will function in a 50Hz or 60Hz network and accepts supply voltage ranging from 100 to 415 VAC and 125 to 250 VDC. Line rated current for this meter is 1A or 5A input and will support Single Phase and Neutral, Three Phase, or Three Phase and Neutral configurations. The range of measurement voltage between Phases is 35 to 690 VAC at 47 to 63 Hz. Measurement range between Phase and Neutral is 20 to 400VAC at 47 to 63 Hz. Communication protocol is Modbus RTU and ASCII 2 wires with RS485 port support. The meter also has two digital inputs or digital outputs, configurable. There are 35 configurable alarms and it supports four tariff schedules. Product dimensions are as follows: width 3.78 inches (96 millimetres), depth 2.83 inches (72 millimetres), height 3.78 inches (96 millimetres) and product weight 15.2 onces (430 g).

METSEPM5310 key specifications

Key specifications: rated current 1 A; rated voltage 415 V AC; flush mounting.

Ordering information for METSEPM5310

• Order code: METSEPM5310
• Manufacturer: Schneider Electric
• Range: PM5000 series
• GTIN / EAN: 3606480614002
• Supplied: each
• Weight: 0.492 kg
• Datasheet: manufacturer datasheet for METSEPM5310

About the PM5000 series range

PM5000 series is a Schneider Electric range with 15 references listed on RMS-SE.Africa.

METSEPM5310 — frequently asked questions

What is the rated current of METSEPM5310?

METSEPM5310 is rated 1 A.

Where is the datasheet for METSEPM5310?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.

Is METSEPM5310 a genuine Schneider Electric product?

Yes. METSEPM5310 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
