| Product Series | Filter products byMasterpact MTZ |
|---|
Schneider ElectricAir Circuit breakers (ACB's)
LV850045 – Digital Module “Modbus legacy dataset” for Micrologic X | Schneider Electric
Order code
List R3 370.50 Your price R2 291.94
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Digital Module “Modbus legacy dataset” for Micrologic X — Schneider Electric order code LV850045.
Download datasheet (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV850045 — Digital Module "Modbus legacy dataset" for Micrologic X, an air circuit breaker from the Schneider Electric Masterpact MTZ range. Listed under Air Circuit Breakers (ACBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV850045
This is the digital module "Modbus legacy dataset" for Micrologic X trip unit on MasterPact MTZ offer. A digital module is an advanced function that can be uploaded in Micrologic X trip unit at any stage of the product life cycle. Digital modules allow you to customize MasterPact MTZ circuit breaker to your specific needs. The digital modules are available 24/7 on the Schneider Electric GoDigital store (godigital.schneider-electric.com). The upload of the digital modules is made without interrupting power, using EcoStruxure Power Commission software and a USB cable. The Modbus legacy dataset is compatible with the Micrologic control unit of Masterpact NT/NW devices. The Modbus legacy dataset can be used with EIFE, IFE, IFE gateway and IFM (LV434000). The EIFE firmware (greater than or equal to V004.000.xxx) is compatible with this digital module. The IFE standalone (LV434001) firmware (greater than or equal to V004.000.xxx) is compatible with this digital module. The Micrologic X control unit firmware (greater than or equal to V002.000.xxx) is compatible with this digital module. Earlier firmware versions need to be upgraded. The benefit is to allow the system integrator to keep the existing Modbus driver within the supervision software. It allows installation with both Masterpact NT/NW and Masterpact MTZ devices.
Ordering information for LV850045
- Order code:
LV850045 - Manufacturer: Schneider Electric
- Range: Masterpact MTZ
- GTIN / EAN: 3606489503048
- Supplied: each
- Weight: 0.01 kg
- Datasheet: manufacturer datasheet for LV850045
About the Masterpact MTZ range
Masterpact MTZ is a Schneider Electric range with 840 references listed on RMS-SE.Africa, from 5 A to 6300 A.
LV850045 — frequently asked questions
Where is the datasheet for LV850045?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV850045 a genuine Schneider Electric product?
Yes. LV850045 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products byLV850045 – Digital Module "Modbus legacy dataset" for Micrologic X Schneider Electric |
|---|---|
| Brand | Filter products bySchneider Electric |
| Product Series | Filter products byMasterpact MTZ |
| GTIN / EAN | Filter products by3606489503048 |
| Lifecycle status | Filter products byCurrent |
Documents
| Datasheet | Download datasheet |
|---|
Other specifications
| Related Categories | Filter products byMetering,Filter products byPower Capacitors For PF Correction |
|---|---|
| SKU/Code/Partnumber | Filter products byLV850045 |
| Iternational GTIN | Filter products by3606489503048 |
