LV850005 – Digital Module “Masterpact operation assistant” for Micrologic X | Schneider Electric
Order code
List R1 785.00 Your price R1 213.80
Per unit · volume pricing available on request
excl. VAT R1 395.87 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Digital Module “Masterpact operation assistant” for Micrologic X — Schneider Electric order code LV850005.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV850005 — Digital Module "Masterpact operation assistant" for Micrologic X, an air circuit breaker from the Schneider Electric Masterpact MTZ range. Listed under Air Circuit Breakers (ACBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV850005
This is the digital module "Masterpact operation assistant" for Micrologic X trip unit on Masterpact MTZ offer. A digital module is an advanced function that can be uploaded in Micrologic X trip unit at any stage of the product life cycle. Digital modules allow you to customize MasterPact MTZ circuit breaker to your specific needs. The digital modules are available 24/7 on the Schneider Electric GoDigital store (godigital.schneider-electric.com). The upload of the digital modules is made without interrupting power, using EcoStruxure Power Commission software and a USB cable. This digital module assists the maintenance operator in reclosing and opening the circuit breaker, by delivering instructions such as reset (if applicable) or charge spring (if applicable). It displays circuit breaker status like ready to close status, coil status or spring status. This is a real onsite guidance. The benefit is to close and to open the circuit breaker from a distance of few meters, and to reduce reclosing time without the need for documentation and lengthily training. The full benefit of the function is given when installed with the diagnostic and communicating voltage release (MX, MN, XF).
Ordering information for LV850005
- Order code:
LV850005 - Manufacturer: Schneider Electric (formerly Merlin Gerin)
- Range: Masterpact MTZ
- GTIN / EAN: 3606481156259
- Supplied: each
- Weight: 0 kg
- Datasheet: manufacturer datasheet for LV850005
About the Masterpact MTZ range
Masterpact MTZ is a Schneider Electric range with 840 references listed on RMS-SE.Africa, from 5 A to 6300 A.
LV850005 — frequently asked questions
Where is the datasheet for LV850005?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV850005 a genuine Schneider Electric product?
Yes. LV850005 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV850005 – Digital Module "Masterpact operation assistant" for Micrologic X Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Masterpact MTZ |
| GTIN / EAN | 3606481156259 |
| Lifecycle status | Filter products by Current |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Related Categories | Filter products by Metering, Filter products by Power Capacitors For PF Correction |
|---|---|
| SKU/Code/Partnumber | LV850005 |
| Iternational GTIN | 3606481156259 |
