Schneider ElectricAir Circuit breakers (ACB's)
LV848092 – Circuit breaker basic frame, Masterpact MTZ2 40H1, 4000 A, 66 kA at 440 VAC 50/60 Hz, 3 poles, fixed, without Micrologic | Schneider Electric
Order code
List R183 323.77 Your price R124 660.17
Per unit · volume pricing available on request
excl. VAT R143 359.20 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Circuit breaker basic frame, Masterpact MTZ2 40H1, 4000 A, 66 kA at 440 VAC 50/60 Hz, 3 poles, fixed, without Micrologic — Schneider Electric order code LV848092. Rated current 4000 A; 3P; breaking capacity 66 kA at 440 V AC; rated voltage 440 V AC.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV848092 — Circuit breaker basic frame, Masterpact MTZ2 40H1, 4000 A, 66 kA at 440 VAC 50/60 Hz, 3 poles, fixed, without Micrologic by Schneider Electric. Listed under Air Circuit Breakers (ACBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV848092
This is a basic frame for 3 poles Masterpact MTZ2 40H1 fixed circuit breaker. Masterpact MTZ is the last generation of high current air circuit breakers up to 6300 A embedding advanced digital technologies. Masterpact MTZ is designed to protect electrical systems from damage caused by overloads, short circuits and equipment ground faults. The breaking capacity (Icu) is 66kA rms at 440VAC 50/60Hz. The rated current is 4000A. The basic frame must be associated with the corresponding chassis which has also to be ordered separately. This basic frame is compatible with Micrologic X control unit which has to be ordered separately. With Micrologic X control unit, Masterpact MTZ contributes to safety and energy efficiency. It can be equipped with a variety of optional functions and accessories. The dimensions are 422mm (W) x 352mm (H) x 300mm (D). It ensures compliance with international standards (IEC 60947), UL489, CCC, EAC and marine specifications. Masterpact MTZ and Micrologic X are part of EcoStruxure architecture system.
LV848092 key specifications
Key specifications: rated current 4000 A; 3P; breaking capacity 66 kA at 440 V AC; rated voltage 440 V AC; 50 / 60 Hz; fixed mounting.
Ordering information for LV848092
- Order code:
LV848092 - Manufacturer: Schneider Electric
- Range: Masterpact MTZ
- GTIN / EAN: 3606480808517
- Supplied: each
- Weight: 47.251 kg
- Datasheet: manufacturer datasheet for LV848092
About the Masterpact MTZ range
Masterpact MTZ is a Schneider Electric range with 840 references listed on RMS-SE.Africa, from 5 A to 6300 A.
LV848092 — frequently asked questions
What is the rated current of LV848092?
LV848092 is rated 4000 A.
How many poles does LV848092 have?
LV848092 is a 3P device.
What is the breaking capacity of LV848092?
The catalogue states 66 kA at 440 V AC for LV848092. Check the datasheet for the value at your system voltage.
Where is the datasheet for LV848092?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV848092 a genuine Schneider Electric product?
Yes. LV848092 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV848092 – circuit breaker basic frame, Masterpact MTZ2 40H1, 4000 A, 66 kA at 440 VAC 50/60 Hz, 3 poles, fixed, without Micrologic Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Masterpact MTZ |
| GTIN / EAN | 3606480808517 |
| Lifecycle status | Filter products by Current |
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated current (Iu) | Filter products by 4000 A |
| Rated voltage (Ue) | Filter products by 440 V AC |
| Operating Voltage | Filter products by 440 VAC |
| Rated Frequency | Filter products by 50 / 60 Hz |
| Max Break Capacity | Filter products by 66 kA at 440 V AC |
Mechanical & mounting
| Mounting | Filter products by fixed |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Breaking capacity icu | Filter products by 66 kA at 440 V |
|---|---|
| Related Categories | Filter products by Metering, Filter products by Power Capacitors For PF Correction |
| SKU/Code/Partnumber | LV848092 |
| Iternational GTIN | 3606480808517 |
