circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d

Key specifications
Rated current (Iu)	Filter products by 400 A
Rated voltage (Ue)	Filter products by 415 V AC
Number of poles	Filter products by 4P
Max Break Capacity	Filter products by 36 kA at 415 V AC
Product Series	Filter products by EasyPact CVS
Mounting	Filter products by fixed

Schneider Electric Moulded Case Circuit Breakers (MCCBs)

LV540506 – circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d Schneider Electric

Name: LV540506 - circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d Schneider Electric
Brand: Schneider Electric
SKU: LV540506
Price: 16787.44 ZAR
Availability: InStock

Order code

Select a variant in this series

Rating

Poles

Breaking capacity

36 kA at 415 V AC
50 kA at 415 V AC

Rated voltage

415 V
415 V AC

Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.

List price

R16 787.44

Excluding VAT · per unit · volume pricing available on request

Listed in stock — availability is re-confirmed on every order

Circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d — Schneider Electric order code LV540506. Rated current 400 A; 4P; breaking capacity 36 kA at 415 V AC; rated voltage 415 V AC.

Find documents for this part

Ordering & delivery

Contact us for bulk pricing, lead times and ordering codes.
Minimum order: 1 unit.
Manufacturer's standard warranty applies.
Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.

Authorised Schneider Electric distributor
Genuine product with manufacturer warranty
Formal quotations with written lead times

Overview

LV540506 — Circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d by Schneider Electric.

EasyPact CVS400F is a 4 poles 4d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds an electronic ETS 2.3 trip unit, with 400A rating. ETS 2.3 trip unit provides adjustable long time and short time protections, and a fixed instantaneous protection. This 4 poles version (185mm x 255mm x 110mm) comes with a variety of optional functions and accessories. EasyPact CVS400F is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front face device (IEC 60664-1).

Key specifications: rated current 400 A; 4P; breaking capacity 36 kA at 415 V AC; rated voltage 415 V AC; fixed mounting.

Ordering information

Order code: LV540506
Manufacturer: Schneider Electric (formerly Other supplier)
Range: EasyPact CVS
GTIN / EAN: 3606480249044
Supplied: each
Weight: 8.23 kg
ETIM class: EC000228
Datasheet: manufacturer datasheet for LV540506

Technical specifications

Data supplied by the manufacturer. Confirm against the official datasheet before ordering.

Identification & ordering

Product Name	Filter products by LV540506 – circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d Schneider Electric
Brand	Filter products by Schneider Electric
Product Series	Filter products by EasyPact CVS
GTIN / EAN	Filter products by 3606480249044
Lifecycle status	Filter products by Current
ETIM class	Filter products by EC000228

Electrical ratings

Number of poles	Filter products by 4P
Rated current (Iu)	Filter products by 400 A
Rated voltage (Ue)	Filter products by 415 V AC
Operating Voltage	Filter products by 415 VAC
Max Break Capacity	Filter products by 36 kA at 415 V AC

Mechanical & mounting

Mounting	Filter products by fixed

Other specifications

Related Categories	Filter products by Metering, Filter products by Power Capacitors For PF Correction
SKU/Code/Partnumber	Filter products by LV540506
Iternational GTIN	Filter products by 3606480249044

Higher-rated in this range 2

Same series, a larger rating — where the duty is heavier than this part covers.

More in the EasyPact CVS range 2

Same series, same mounting and the same documentation set.

Alternatives on our other RMS storefronts

RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.

Comparable rangeTmax XT MCCB range at RMS-ABB.Africa (opens in a new tab)
A range-level suggestion, not a confirmed part match. Match voltage, current rating, breaking capacity and poles on the datasheet — or ask us to confirm the equivalent before ordering.
Comparable rangeHager h3 MCCB range at RMS-EM.Africa (opens in a new tab)
A range-level suggestion, not a confirmed part match. Match voltage, current rating, breaking capacity and poles on the datasheet — or ask us to confirm the equivalent before ordering.

Quick answers

What is LV540506?

LV540506 is the order code for circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d. It belongs to our Moulded Case Circuit Breakers (MCCBs) range. RMS-SE.Africa supplies it as genuine Schneider Electric product, sourced through the manufacturer's distribution channel.

Is it available?

It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.

How do I get a formal quotation?

Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.

Do I pay when I order?

No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
