Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV431564 – Spreaders 35 mm to 45 mm pitch, ComPact NSX 100/160/250, 4 poles, set of 4 parts | Schneider Electric
Order code
List R568.00 Your price R386.24
Per unit · volume pricing available on request
excl. VAT R444.18 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Spreaders 35 mm to 45 mm pitch, ComPact NSX 100/160/250, 4 poles, set of 4 parts — Schneider Electric order code LV431564. Rated current 250 A; 4P.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV431564 — Spreaders 35 mm to 45 mm pitch, ComPact NSX 100/160/250, 4 poles, set of 4 parts, a moulded case circuit breaker from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV431564
These accessories are spreaders for 3 poles Compact NSX 100/160/250 and EasyPact CVS 100/160/250. They are screwed to the circuit-breaker terminals to increase the pitch between poles from 35mm to 45mm. The rated current is up to 250 A. These spreaders are supplied with flexible interphase barriers for insulation reinforcement. They are sold by set of 4 parts.
LV431564 key specifications
Key specifications: rated current 250 A; 4P.
Availability and replacement
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV431564
- Order code:
LV431564 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480019647
- Supplied: each
- Weight: 0.29 kg
- ETIM class: EC002019
- Datasheet: manufacturer datasheet for LV431564
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV431564 — frequently asked questions
What is the rated current of LV431564?
LV431564 is rated 250 A.
How many poles does LV431564 have?
LV431564 is a 4P device.
Where is the datasheet for LV431564?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV431564 a genuine Schneider Electric product?
Yes. LV431564 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV431564 – spreaders 35 mm to 45 mm pitch, ComPact NSX 100/160/250, 4 poles, set of 4 parts Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480019647 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC002019 |
Electrical ratings
| Number of poles | Filter products by 4P |
|---|---|
| Rated current (Iu) | Filter products by 250 A |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Related Categories | Filter products by Metering, Filter products by Power Capacitors For PF Correction |
|---|---|
| SKU/Code/Partnumber | LV431564 |
| Iternational GTIN | 3606480019647 |
