Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV429805 – Circuit breaker ComPact NSX100N, 50 kA at 415 VAC, MicroLogic 2.2 trip unit 100 A, 4 poles 4d | Schneider Electric
Order code
List R7 768.39 Your price R5 282.51
Per unit · volume pricing available on request
excl. VAT R6 074.89 incl.
Discontinued — remaining stock confirmed on quote
Circuit breaker ComPact NSX100N, 50 kA at 415 VAC, MicroLogic 2.2 trip unit 100 A, 4 poles 4d — Schneider Electric order code LV429805. Rated current 100 A; 4P 4d; breaking capacity 50 kA at 415 V AC; rated voltage 415 V AC.
Discontinued — remaining stock confirmed on quote
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV429805 — Circuit breaker ComPact NSX100N, 50 kA at 415 VAC, MicroLogic 2.2 trip unit 100 A, 4 poles 4d from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV429805
This Compact NSX100N is a complete 4P 4d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 2.2 trip unit, with 100A rating. Micrologic 2.2 trip unit provides adjustable long time and short time protections, and a fixed instantaneous protection. This 4 poles version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100N is part of Schneider Electric EcoStruxure Power architecture.
LV429805 key specifications
Key specifications: rated current 100 A; 4P 4d; breaking capacity 50 kA at 415 V AC; rated voltage 415 V AC.
Availability and replacement
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV429805
- Order code:
LV429805 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480007569
- Supplied: each
- Weight: 2.385 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV429805
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV429805 — frequently asked questions
What is the rated current of LV429805?
LV429805 is rated 100 A.
How many poles does LV429805 have?
LV429805 is a 4P 4d device.
What is the breaking capacity of LV429805?
The catalogue states 50 kA at 415 V AC for LV429805. Check the datasheet for the value at your system voltage.
Is LV429805 discontinued, and what replaces it?
Yes. Schneider Electric has announced the end of commercialisation of LV429805 (last orders 2023/12/31). The named successor is ComPacT NSX (new generation); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for LV429805?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV429805 a genuine Schneider Electric product?
Yes. LV429805 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV429805 – circuit breaker ComPact NSX100N, 50 kA at 415 VAC, MicroLogic 2.2 trip unit 100 A, 4 poles 4d Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480007569 |
| Lifecycle status | Filter products by Discontinued |
| ETIM class | Filter products by EC000228 |
Electrical ratings
| Number of poles | Filter products by 4P 4d |
|---|---|
| Rated current (Iu) | Filter products by 100 A |
| Rated voltage (Ue) | Filter products by 415 V AC |
| Operating Voltage | Filter products by 415 VAC |
| Max Break Capacity | Filter products by 50 kA at 415 V AC |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Discontinued on | Filter products by 2023-12-25 |
|---|---|
| Breaking capacity icu | Filter products by 50 kA at 415 V |
| Replaced by | Filter products by C10N42D100 |
| Trip unit | Filter products by MicroLogic 2.2 |
| Trip unit rating | Filter products by 100 A |
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | LV429805 |
| Iternational GTIN | 3606480007569 |
| Mount Type | Filter products by Plug-in |
