Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV429014 – Circuit breaker basic frame, ComPact NSX100B, 25 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles | Schneider Electric
Order code
List R2 751.97 Your price R1 871.34
Per unit · volume pricing available on request
excl. VAT R2 152.04 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Circuit breaker basic frame, ComPact NSX100B, 25 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles — Schneider Electric order code LV429014. Rated current 100 A; 3P; breaking capacity 25 kA at 415 V AC; rated voltage 415 V AC.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV429014 — Circuit breaker basic frame, ComPact NSX100B, 25 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles from the Schneider Electric Compact NSX <630 range. Listed under Moulded Case Circuit Breakers (MCCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About LV429014
This is a 3 poles basic frame for Compact NSX100B. Compact NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit which has to be ordered separately The breaking capacity Icu is 25kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 105mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100B is part of Schneider Electric EcoStruxure Power architecture.
LV429014 key specifications
Key specifications: rated current 100 A; 3P; breaking capacity 25 kA at 415 V AC; rated voltage 415 V AC; 50 / 60 Hz.
Availability and replacement
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Schneider Electric names ComPacT NSX (new generation) as the successor to the Compact NSX <630 range. Schneider substitution guide: same frame sizes. Ask the sales desk to confirm the exact replacement reference before ordering.
Schneider Electric substitution guide (manufacturer document)
Ordering information for LV429014
- Order code:
LV429014 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480006487
- Supplied: each
- Weight: 1.414 kg
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV429014
About the Compact NSX <630 range
Compact NSX <630 is a Schneider Electric range with 597 references listed on RMS-SE.Africa, from 2.5 A to 630 A. Schneider Electric has announced ComPacT NSX (new generation) as its successor.
LV429014 — frequently asked questions
What is the rated current of LV429014?
LV429014 is rated 100 A.
How many poles does LV429014 have?
LV429014 is a 3P device.
What is the breaking capacity of LV429014?
The catalogue states 25 kA at 415 V AC for LV429014. Check the datasheet for the value at your system voltage.
Is LV429014 discontinued, and what replaces it?
Yes. Schneider Electric has announced the end of commercialisation of LV429014 (last orders 2023/12/31). The named successor is ComPacT NSX (new generation); the sales desk confirms the exact replacement reference and remaining stock.
Where is the datasheet for LV429014?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LV429014 a genuine Schneider Electric product?
Yes. LV429014 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | LV429014 – circuit breaker basic frame, ComPact NSX100B, 25 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Compact NSX <630 |
| GTIN / EAN | 3606480006487 |
| Lifecycle status | Filter products by End of commercialisation announced |
| ETIM class | Filter products by EC000228 |
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated current (Iu) | Filter products by 100 A |
| Rated voltage (Ue) | Filter products by 415 V AC |
| Operating Voltage | Filter products by 415 VAC |
| Rated Frequency | Filter products by 50 / 60 Hz |
| Max Break Capacity | Filter products by 25 kA at 415 V AC |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Breaking capacity icu | Filter products by 25 kA at 415 V |
|---|---|
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | LV429014 |
| Iternational GTIN | 3606480006487 |
| Mount Type | Filter products by Plug-in |
