Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV429000 – circuit breaker basic frame, ComPact NSX100F, 36 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 2 poles Schneider Electric
Order code
R3 160.30
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Circuit breaker basic frame, ComPact NSX100F, 36 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 2 poles — Schneider Electric order code LV429000. Rated current 100 A; 2P; breaking capacity 36 kA at 415 V AC; rated voltage 415 V AC.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV429000 — Circuit breaker basic frame, ComPact NSX100F, 36 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 2 poles from the Schneider Electric Compact NSX <630 range.
Key specifications: rated current 100 A; 2P; breaking capacity 36 kA at 415 V AC; rated voltage 415 V AC; 50 / 60 Hz.
Ordering information
- Order code:
LV429000 - Manufacturer: Schneider Electric
- Range: Compact NSX <630
- GTIN / EAN: 3606480006449
- Supplied: each
- ETIM class: EC000228
- Datasheet: manufacturer datasheet for LV429000
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Number of poles | Filter products by 2P |
|---|---|
| Rated current (Iu) | Filter products by 100 A |
| Rated voltage (Ue) | Filter products by 415 V AC |
| Operating Voltage | Filter products by 415 VAC |
| Rated Frequency | Filter products by 50 / 60 Hz |
| Max Break Capacity | Filter products by 36 kA at 415 V AC |
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Filter products by LV429000 |
| Iternational GTIN | Filter products by 3606480006449 |
| Mount Type | Filter products by Plug-in |
