Schneider ElectricMoulded Case Circuit Breakers (MCCBs)
LV426612 – switch disconnector Compact NSXm NA, 3P, 160A rating, EverLink connectors Schneider Electric
Order code
Select a variant in this series
- 3P
- 4P
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
R4 624.35
Excluding VAT · per unit · volume pricing available on request
End of commercialisation announced. Ask us to confirm remaining stock or to quote the current replacement.
Listed in stock — availability is re-confirmed on every order
Switch disconnector Compact NSXm NA, 3P, 160A rating, EverLink connectors — Schneider Electric order code LV426612. Rated current 160 A; 3P; DIN rail mounting.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LV426612 — Switch disconnector Compact NSXm NA, 3P, 160A rating, EverLink connectors, a moulded case circuit breaker from the Schneider Electric Compact NSXm switch disconnector range.
It is a Compact NSXm NA 160A switch disconnector, category AC-22A/AC-23A. It is designed to ensure a reliable isolation switching. It offers new features like Everlink technology, DIN rail and plate mounting capability. It embeds new spring type auxiliaries externally visible. This 4 poles version is compatible with Compact NSXm circuit breakers accessories and auxiliaries. Compact NSXm NA has the same footprint as Compact NSXm circuit breakers, 108mm (W) x 137mm (H) x 80mm (D). It ensures compliance with international standards (IEC 60947/CCC/EAC) and marine specifications.
Key specifications: rated current 160 A; 3P; DIN rail mounting.
Availability notice: Schneider Electric has announced the end of commercialisation of this reference (announced 2021/12/15, last orders 2023/12/31). Stock may still be available; ask us to confirm, or to quote the current replacement.
Ordering information
- Order code:
LV426612 - Manufacturer: Schneider Electric
- Range: Compact NSXm switch disconnector
- GTIN / EAN: 3606481176516
- Supplied: each
- Weight: 1.552 kg
- ETIM class: EC000216
- Datasheet: manufacturer datasheet for LV426612
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated current (Iu) | Filter products by 160 A |
Mechanical & mounting
| Mounting | Filter products by DIN rail |
|---|
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Filter products by LV426612 |
| Iternational GTIN | Filter products by 3606481176516 |
