LC1K1610B7 – TeSys K contactor – 3P – AC-3 <= 440 V 16 A - 1 NO aux. - 24 V AC coil | Schneider Electric
Order code
List R806.08 Your price R548.13
Per unit · volume pricing available on request
excl. VAT R630.35 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
TeSys K contactor – 3P – AC-3 <= 440 V 16 A - 1 NO aux. - 24 V AC coil — Schneider Electric order code LC1K1610B7. Rated current 16 A; 3P; rated voltage 440 V; 24 V AC coil.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Poles3P2 options
- 3P
- 4P
Coil voltage24 V AC8 options
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LC1K1610B7 — TeSys K contactor – 3P – AC-3 <= 440 V 16 A – 1 NO aux. – 24 V AC coil by Schneider Electric. Listed under Contactors on the Schneider Electric catalogue at RMS-SE.Africa.
About LC1K1610B7
TeSys K contactor, 3 poles (3NO), for motor control applications up to 16A/690V AC-3 (7.5kW@400V). It provides a 24V 50/60Hz AC coil, 1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
LC1K1610B7 key specifications
Key specifications: rated current 16 A; 3P; rated voltage 440 V; 24 V AC coil.
Ordering information for LC1K1610B7
- Order code:
LC1K1610B7 - Manufacturer: Schneider Electric (formerly Telemecanique)
- Range: TeSys k
- GTIN / EAN: 3389110124286
- Supplied: each
- Weight: 0.178 kg
- ETIM class: EC000066
- Datasheet: manufacturer datasheet for LC1K1610B7
How to read the order code
LC1K— TeSys K contactor16— AC-3 rating 16 A10— 1 NO auxiliary contactB7— coil 24 V AC
Ordering options in this range
Same product, different coil / control voltage:
LC1K1610F7— 110 V ACLC1K1610P7— 230 V AC
About the TeSys k range
TeSys k is a Schneider Electric range with 113 references listed on RMS-SE.Africa, from 2 A to 20 A. Coil voltages in the range: 24 V DC, 48 V AC, 110 V AC, 24 V AC, 230 V AC, 380…400 V AC, 400 V AC, 48 V DC. It spans Contactors, Mini Contactors.
LC1K1610B7 — frequently asked questions
What is the rated current of LC1K1610B7?
LC1K1610B7 is rated 16 A.
What coil or control voltage does LC1K1610B7 use?
LC1K1610B7 is supplied with a 24 V AC coil. Other coil voltages in the range appear under “Ordering options” above where the catalogue lists them.
How many poles does LC1K1610B7 have?
LC1K1610B7 is a 3P device.
Where is the datasheet for LC1K1610B7?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is LC1K1610B7 a genuine Schneider Electric product?
Yes. LC1K1610B7 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | Filter products by LC1K1610B7 – TeSys K contactor – 3P – AC-3 <= 440 V 16 A – 1 NO aux. – 24 V AC coil Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by TeSys k |
| GTIN / EAN | 3389110124286 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000066 |
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated current (Iu) | Filter products by 16 A |
| Rated current AC-3 (Ie) | Filter products by 16 A |
| Rated voltage (Ue) | Filter products by 440 V |
Power & coil
| Coil voltage (Uc) | Filter products by 24 V AC |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Rated power kw | Filter products by 7.5 kW at 400 V |
|---|---|
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
| SKU/Code/Partnumber | Search products for LC1K1610B7 |
| Iternational GTIN | 3389110124286 |
| Mount Type | Filter products by Plug-in |
