LB1LD03M55 – TeSys integral – protection module – AC-43 – thermal-magnetic – 28…40 A Schneider Electric
Order code
R14 483.12
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
TeSys integral – protection module – AC-43 – thermal-magnetic – 28…40 A — Schneider Electric order code LB1LD03M55. Rated current 40 A; rated voltage 400 V.
Accessories & add-ons 1
- TeSys D control relay – 5 NO – <= 690 V – 115 V AC standard coil Schneider ElectricCAD50FE7 Original price was: R716.00.R486.88Current price is: R486.88.Add
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LB1LD03M55 — TeSys integral – protection module – AC-43 – thermal-magnetic – 28…40 A, a contactor from the Schneider Electric TeSys Integral 18, 32, 63 range.
TeSys Integral thermal magnetic protection module, for mounting on contactor breakers LD1LD, LD4LD, LD5LD. With an adjustable thermal setting range Irth 28-40A, a tripping class 20, and a magnetic protection range 240-480A (6 to 12 Irth max), it protects motors 15 to 22kW@400V AC-43 for normal starting applications. It ensures phase imbalance protection and compensation of the thermal protection from -20 to 60°C. Manual reset is done by the control knob of the contactor breaker, remote reset requires an additional reset module mounted on the contactor breaker (to be ordered separately). Multi standards certified (IEC, UL, CSA, Marine), Green Premium compliant (RoHS/REACh).
Key specifications: rated current 40 A; rated voltage 400 V.
Ordering information
- Order code:
LB1LD03M55 - Manufacturer: Schneider Electric (formerly Telemecanique)
- Range: TeSys Integral 18, 32, 63
- GTIN / EAN: 3389110180688
- Supplied: each
- Weight: 1.038 kg
- ETIM class: EC000617
- Datasheet: manufacturer datasheet for LB1LD03M55
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
Electrical ratings
| Rated current (Iu) | Filter products by 40 A |
|---|---|
| Rated voltage (Ue) | Filter products by 400 V |
| Rated operational voltage | Filter products by 400 V |
| Operating Voltage | Filter products by 400V |
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | Filter products by LB1LD03M55 |
| Iternational GTIN | Filter products by 3389110180688 |
| Mount Type | Filter products by Plug-in |
