Schneider ElectricMiniature Circuit Breakers (MCB's)
EZ9S16163 – Easy9 switch disconnector – 1P – 63 A – 230 V | Schneider Electric
Order code
List R83.00 Your price R56.44
Per unit · volume pricing available on request
excl. VAT R64.91 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Easy9 switch disconnector – 1P – 63 A – 230 V — Schneider Electric order code EZ9S16163. Rated current 63 A; 1P; rated voltage 230 V; IP20.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Rated voltage230 V2 options
- 230 V
- 400 V
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
EZ9S16163 — Easy9 switch disconnector – 1P – 63 A – 230 V, a miniature circuit breaker from the Schneider Electric Easy9 switch-disconnectors range. Listed under Miniature Circuit Breakers (MCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About EZ9S16163
This Easy9 is a modular and reliable switch disconnector. This switch disconnector is used for control (opening and closing of circuits under load). This product is also used for disconnection of on-load electrical circuits already protected against overload and short-circuits. It has a position contact indication suitable for industrial isolation according to IEC 60947-3 standard. It is a 1P switch disconnector with 63A rated current. Electrical endurance goes up to 1500 cycles, and mechanical endurance goes up to 8500 cycles. The Ue rated operational voltage is 230VAC. The Ui rated insulation voltage is 500VAC. It has a Uimp rated impulse withstand voltage of 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The dimensions are (W) 18mm x (H) 81mm x (D) 66.5mm. The color is light grey (RAL7035). According to IEC 60529 standard, the degree of protection is IP20 or IP40 in modular enclosure. The pollution degree is NA. The operating temperature is -5°C to 55°C. The storage temperature is -5°C to 70 °C. This product complies with IEC 60947-3 standard.
EZ9S16163 key specifications
Key specifications: rated current 63 A; 1P; rated voltage 230 V; IP20; DIN rail mounting.
Ordering information for EZ9S16163
- Order code:
EZ9S16163 - Manufacturer: Schneider Electric
- Range: Easy9 switch-disconnectors
- GTIN / EAN: 3606480589942
- Supplied: each
- Weight: 0.081 kg
- ETIM class: EC000216
- Datasheet: manufacturer datasheet for EZ9S16163
About the Easy9 switch-disconnectors range
Easy9 switch-disconnectors is a Schneider Electric range with 4 references listed on RMS-SE.Africa.
EZ9S16163 — frequently asked questions
What is the rated current of EZ9S16163?
EZ9S16163 is rated 63 A.
How many poles does EZ9S16163 have?
EZ9S16163 is a 1P device.
Where is the datasheet for EZ9S16163?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Schneider Electric publishes them.
Is EZ9S16163 a genuine Schneider Electric product?
Yes. EZ9S16163 is supplied through the manufacturer’s authorised channel with the standard Schneider Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Product Name | EZ9S16163 – Easy9 switch disconnector – 1P – 63 A – 230 V Schneider Electric |
|---|---|
| Brand | Filter products by Schneider Electric |
| Product Series | Filter products by Easy9 switch-disconnectors |
| GTIN / EAN | 3606480589942 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000216 |
Electrical ratings
| Number of poles | Filter products by 1P |
|---|---|
| Rated current (Iu) | Filter products by 63 A |
| Rated voltage (Ue) | Filter products by 230 V |
Mechanical & mounting
| Mounting | Filter products by DIN rail |
|---|
Environment & protection
| Degree of protection (IP) | Filter products by IP20 |
|---|
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| Related Categories | Filter products by Plug – in Relays, Filter products by Timers & Control Relays |
|---|---|
| SKU/Code/Partnumber | EZ9S16163 |
| Iternational GTIN | 3606480589942 |
