Schneider ElectricMiniature Circuit Breakers (MCB's)
A9F75450 – Miniature circuit-breaker, Acti9 iC60N, 4P, 50 A, D curve, 6000 A (IEC 60898-1), 10 kA (IEC 60947-2) | Schneider Electric
Order code
List R1 740.60 Your price R1 183.61
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Miniature circuit-breaker, Acti9 iC60N, 4P, 50 A, D curve, 6000 A (IEC 60898-1), 10 kA (IEC 60947-2) — Schneider Electric order code A9F75450.
Download datasheet (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
A9F75450 — Miniature circuit-breaker, Acti9 iC60N, 4P, 50 A, D curve, 6000 A (IEC 60898-1), 10 kA (IEC 60947-2) by Schneider Electric. Listed under Miniature Circuit Breakers (MCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About A9F75450
This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 4P circuit breaker with 4 protected poles, 50A rated current and D tripping curve. The rated short circuit breaking capacity goes up to 20kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 8 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 72mm x (H) 85mm x (D) 78.5mm. The weight is 0.5kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35C to 70C. The storage temperature is -40C to 85C.
A9F75450 key specifications
number of poles 4P; tripping curve D.
Ordering information for A9F75450
- Order code:
A9F75450 - Manufacturer: Schneider Electric
- Range: Acti 9 iC60
- GTIN / EAN: 3606480081217
- ETIM class: EC000042
- Datasheet: manufacturer datasheet for A9F75450
Prices in ZAR excluding VAT; stock and lead time are confirmed on every written quotation from RMS Measurement & Control, Johannesburg.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Brand | Filter products by Schneider Electric |
|---|---|
| GTIN / EAN | Filter products by 3606480081217 |
| Range | Filter products by Acti 9 iC60 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000042 |
Electrical ratings
| Number of poles | Filter products by 4P |
|---|---|
| Tripping curve | Filter products by D |
Documents
| Datasheet | Download datasheet |
|---|
Other specifications
| SKU/Code/Partnumber | Filter products by A9F75450 |
|---|
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
