Save 32%
Impulse relay iTL+ - 1P+N - 1NO - 16A - coil 230 VAC 50Hz
Key specifications
Number of polesFilter products by 1P+N
Coil voltage (Uc)Filter products by 230 V AC

Schneider ElectricUncategorized

A9C15032 – Impulse relay iTL+ – 1P+N – 1NO – 16A – coil 230 VAC 50Hz | Schneider Electric

Order code

List price

List R1 707.50 Your price R1 161.10

Excluding VAT · per unit · volume pricing available on request

Listed in stock — availability is re-confirmed on every order

Impulse relay iTL+ – 1P+N – 1NO – 16A – coil 230 VAC 50Hz — Schneider Electric order code A9C15032.

Download datasheet (opens in a new tab)

Accessories & add-ons 6
Ordering & delivery
  • Contact us for bulk pricing, lead times and ordering codes.
  • Minimum order: 1 unit.
  • Manufacturer's standard warranty applies.
  • Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
  • Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
  • Authorised Schneider Electric distributor
  • Genuine product with manufacturer warranty
  • Formal quotations with written lead times
SKU: A9C15032 Category: Brand:

Overview

A9C15032 — Impulse relay iTL+ – 1P+N – 1NO – 16A – coil 230 VAC 50Hz by Schneider Electric. Listed under Uncategorized on the Schneider Electric catalogue at RMS-SE.Africa.

About A9C15032

This Acti9 iTL+ is a silent modular impulse relay. This 1P+N device has 1 normally open contact. The rated current is 16A, 230VAC operating voltage and it operates with 230VAC control voltage. Electrical endurance goes up to 5000000 cycles for AC-21 or 5000000 cycles for AC-22. The switching frequency is 6 switching operations/minute or 100 switching operations/day. The duration of the command order should be between 50ms to 1s. The iTL+ high-performance impulse relay allows remote control of single-phase circuits. It is designed for demanding applications. It is mainly used for lighting control applications. It is DIN rail mountable. The dimensions are (W) 18mm x (H) 84mm x (D) 60mm. The product weight is 70g. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature is from -5C to 55C. The storage temperature is from -40C to 60C. This product is compliant with IEC/EN 60669-2-2 standard.

A9C15032 key specifications

number of poles 1P+N; coil voltage 230 V AC; rated frequency 50 Hz.

Ordering information for A9C15032

Prices in ZAR excluding VAT; stock and lead time are confirmed on every written quotation from RMS Measurement & Control, Johannesburg.

Technical specifications

Data supplied by the manufacturer. Confirm against the official datasheet before ordering.

Identification & ordering

BrandFilter products by Schneider Electric
GTIN / EANFilter products by 3606480376979
RangeFilter products by Acti 9 iTL+
Lifecycle statusFilter products by Current
ETIM classFilter products by EC000188

Electrical ratings

Number of polesFilter products by 1P+N
Rated FrequencyFilter products by 50 Hz

Power & coil

Coil voltage (Uc)Filter products by 230 V AC

Documents

DatasheetDownload datasheet

Other specifications

SKU/Code/PartnumberFilter products by A9C15032

Documents

Published by the manufacturer for this part. Each one opens in a new tab.

Accessories & add-ons

6 items

Similar items

5 items

More in Uncategorized

8 items

Alternatives on our other RMS storefronts

RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.

Quick answers

What is A9C15032?

A9C15032 is the order code for Impulse relay iTL+ – 1P+N – 1NO – 16A – coil 230 VAC 50Hz. It belongs to our Uncategorized range. RMS-SE.Africa supplies it as genuine Schneider Electric product, sourced through the manufacturer's distribution channel.

Is it available?

It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.

How do I get a formal quotation?

Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.

Do I pay when I order?

No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
