Schneider ElectricLoad Break / Changeover Switches
33432 – Basic switch disconnector, Compact NS800 NA, withdrawable, manually operated, 800 A, 690 VAC 50/60 Hz, 3 poles | Schneider Electric
Order code
Select a variant in this series
- 3P
- 4P
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
List R26 015.86 Your price R17 690.78
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Basic switch disconnector, Compact NS800 NA, withdrawable, manually operated, 800 A, 690 VAC 50/60 Hz, 3 poles — Schneider Electric order code 33432.
Download datasheet (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
33432 — Basic switch disconnector, Compact NS800 NA, withdrawable, manually operated, 800 A, 690 VAC 50/60 Hz, 3 poles by Schneider Electric. Listed under Load Break & Changeover Switches on the Schneider Electric catalogue at RMS-SE.Africa.
About 33432
This Compact NS800NA is a 3 poles switch disconnector. It is used to control and isolate electrical distribution circuits. This device is a withdrawable version and is manually operated. The operational current is 800A (AC23A) and the operational voltage is 690V 50/60Hz. This basic version does not include the chassis and the power connections. The dimensions are 327mm (width), 210mm (height) and 147mm (depth). This device complies with IEC 60947-3 standard.
33432 key specifications
number of poles 3P; rated frequency 50 / 60 Hz.
Ordering information for 33432
- Order code:
33432 - Manufacturer: Schneider Electric
- Range: Compact NS switches disconnectors
- GTIN / EAN: 3303430334323
- ETIM class: EC000216
- Datasheet: manufacturer datasheet for 33432
Prices in ZAR excluding VAT; stock and lead time are confirmed on every written quotation from RMS Measurement & Control, Johannesburg.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Brand | Filter products by Schneider Electric |
|---|---|
| GTIN / EAN | Filter products by 3303430334323 |
| Range | Filter products by Compact NS switches disconnectors |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000216 |
Electrical ratings
| Number of poles | Filter products by 3P |
|---|---|
| Rated Frequency | Filter products by 50 / 60 Hz |
Documents
| Datasheet | Download datasheet |
|---|
Other specifications
| SKU/Code/Partnumber | Filter products by 33432 |
|---|
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
More in the Compact NS switches disconnectors range
8 itemsSame series, same mounting and the same documentation set.
More in the Compact NS switches disconnectors range
8 items
64912Chassis locking kit, 1 Ronis keylock with adaptation kit, 1 key, locking in disconnected positionList R2 889.94 Your price R1 965.16View product
64908Mounting brackets on horizontal surface, fixed ComPact NS630b to NS1600, set of 2 partsList R2 241.58 Your price R1 524.27View product
48385ECO Modbus COM module – for drawout NWList R11 021.45 Your price R7 494.59View product
47385Voltage release MN – 380..480 V AC 50/60HzList R4 876.14 Your price R3 315.78View product- 47383Voltage release MN – 200..250 V DC/AC 50/60 HzList R4 963.92 Your price R3 375.47View product
- 47382Voltage release MN – 100..130 V DC/AC 50/60 HzList R4 876.14 Your price R3 315.78View product
- 47380Voltage release MN – 24 V DC/AC 50/60HzList R4 876.14 Your price R3 315.78View product
- 47375Voltage release MX – 380..480 V AC 50/60HzList R4 876.14 Your price R3 315.78View product
Similar items
2 items
Similar items
2 items
More in Load Break / Changeover Switches
8 items
More in Load Break / Changeover Switches
8 items
C104100SSwitch disconnector ComPacT NSX100NA, 4 poles, 100A, AC22A, AC23AList R4 188.50 Your price R2 848.18View product
C103100SSwitch disconnector ComPacT NSX100NA, 3 poles, 100A, AC22A, AC23AList R3 221.93 Your price R2 190.91View product- C102100SSwitch disconnector ComPacT NSX100NA, 2 poles, 100A, AC22A, AC23AList R2 536.32 Your price R1 724.70View product
A9S70790Switch-disconnector iSW-NA – 3P + N – 100 AList R2 856.55 Your price R1 942.45View product- A9S70780Switch-disconnector iSW-NA – 3P + N – 80 AList R2 483.38 Your price R1 688.70View product
- A9S70763Switch-disconnector iSW-NA – 3P + N – 63 AList R603.46 Your price R410.35View product
- A9S70740Switch-disconnector iSW-NA – 3P + N – 40 AList R1 074.10 Your price R730.39View product
A9S65492Switch disconnector iSW – 4P – 125 A – 415 VList R1 926.68 Your price R1 310.14View product
Alternatives on our other RMS storefronts
RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.
- Comparable rangeTmax XT MCCB range at RMS-ABB.Africa (opens in a new tab)
- Comparable rangeHager h3 MCCB range at RMS-EM.Africa (opens in a new tab)
Quick answers
What is 33432?
33432 is the order code for Basic switch disconnector, Compact NS800 NA, withdrawable, manually operated, 800 A, 690 VAC 50/60 Hz, 3 poles. It belongs to our Load Break / Changeover Switches range. RMS-SE.Africa supplies it as genuine Schneider Electric product, sourced through the manufacturer's distribution channel.
Is it available?
It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.
How do I get a formal quotation?
Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.
Do I pay when I order?
No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
