Schneider ElectricMiniature Circuit Breakers (MCB's)
19072 – Auxiliary contact – 1 OC + 1 SD – 6 A – 220..240 V – for NG125 | Schneider Electric
Order code
List R574.73 Your price R390.82
Per unit · volume pricing available on request
excl. VAT R449.44 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Auxiliary contact – 1 OC + 1 SD – 6 A – 220..240 V – for NG125 — Schneider Electric order code 19072.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
View on the Schneider Electric site (opens in a new tab)
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised Schneider Electric distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
19072 — Auxiliary contact – 1 OC + 1 SD – 6 A – 220..240 V – for NG125 by Schneider Electric. Listed under Miniature Circuit Breakers (MCBs) on the Schneider Electric catalogue at RMS-SE.Africa.
About 19072
This Acti9 NG125 electrical auxiliary is an open/close and fault indicating contact mounted on DIN rail. It is dedicated to Acti9 NG125, NG125NA and NG125LMA. It is used for remote indication of the position of the associated device. The 2 contacts changeover indicates “open” or “closed” position of the associated device, and the position of the associated device in the event of electrical fault or actuation of the tripping auxiliary. The width in 9mm pitches is 1. The operating frequency is 50Hz or 60Hz. It also works on direct current. The In rated operational current is from 1A (mini) up to 6A (maxi) depending on the rated voltage. The Ue rated operational voltage is up to 415VAC and 130VDC. The operating temperature is -25C to + 60C. The storage temperature is -40C to + 85C. This product complies with IEC/EN 60947-5-1 standards.
Ordering information for 19072
- Order code:
19072 - Manufacturer: Schneider Electric
- Range: Acti 9 NG125
- GTIN / EAN: 3303430190721
- ETIM class: EC000041
- Datasheet: manufacturer datasheet for 19072
Prices in ZAR excluding VAT; stock and lead time are confirmed on every written quotation from RMS Measurement & Control, Johannesburg.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Brand | Filter products by Schneider Electric |
|---|---|
| GTIN / EAN | 3303430190721 |
| Range | Filter products by Acti 9 NG125 |
| Lifecycle status | Filter products by Current |
| ETIM class | Filter products by EC000041 |
Documents
| Datasheet | View on the Schneider Electric site |
|---|
Other specifications
| SKU/Code/Partnumber | 19072 |
|---|
